CFL Double Turn DE Type • Dimmable • 18W • 3000K • G24q-2 4-Pin

New 2021 Energy Rating: G

Energy Labelling Guide

Dimmable compact fluorescent double turn DE-Type lamp (PLC-E).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads, pendants and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

Stock Code: CLDE18SWW

Related Products

Dimmable compact fluorescent double turn DE-Type lamp (PLC-E).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads, pendants and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • G24q-2 4-Pin cap
  • 3000K warm white colour temperature
  • Colour rendering index ≥85
  • Suitable for dimming
  • Recommended for indoor use only
  • 2 year warranty

Part Code:

CLDE18SWW

Product Name:

CFL Double Turn DE Type 18W Dimmable 3000K G24q-2 4 Pin

Notes:

Suitable for use in emergency luminaires. Separate ballast/control gear required.

Nominal Wattage:

18W

Nominal Luminous Flux:

1210lm

Nominal Life:

10,000 hours

Dimmable:

Dimmable

Cap Type:

G24q-2 4-Pin

Energy Saving:

No

Energy Efficiency Class:

New 2021 Energy Rating: G

Pre-2021: A

Rated Wattage (0.1W Precision):

18.0W

Power Factor λ:

>0.96

Weighted Energy Consumption:

20W

Rated Total Luminous Flux:

1210lm

Colour Temperature:

3000K

Colour Name:

Warm White

Weighted Energy Consumption:

COL830

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

≥80%

Efficiency:

67lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Diameter:

41mm

Height:

146mm

Product Weight:

0.043kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986523319

Single Carton Length:

3.5cm

Single Carton Width:

3.5cm

Single Carton Height:

16.5cm

Single Carton Volume:

202.125cm³

Single Carton Weight:

0.059KG

Inner Carton GS1-128 Barcode:

02050189865233193750

Inner Carton Quantity:

50

Inner Carton Length:

18.5cm

Inner Carton Width:

36.5cm

Inner Carton Height:

17.5cm

Inner Carton Volume:

11816.875cm³

Inner Carton Weight:

3.161kg

Outer Carton GS1-128 Barcode:

020501898652331937200

Outer Carton Quantity:

200

Outer Carton Length:

38.5cm

Outer Carton Width:

39cm

Outer Carton Height:

37.5cm

Outer Carton Volume:

56306.25cm³
