CFL Single Turn S Type • 9W • 4000K • G23 2-Pin

New 2021 Energy Rating: G

Energy Labelling Guide

Compact fluorescent single turn S-Type lamp (PL) 2 Pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Separate ballast/control gear required.

Stock Code: CLS9SCW

Related Products

Compact fluorescent single turn S-Type lamp (PL) 2 Pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • G23 2-Pin cap
  • 4000K cool white colour temperature
  • Colour rendering index ≥85
  • Not suitable for dimming
  • Recommended for indoor use only
  • 2 year warranty

Part Code:

CLS9SCW

Product Name:

CFL Single Turn S Type 9W 4000K G23 2 Pin

Notes:

Separate ballast/control gear required.

Nominal Wattage:

9W

Nominal Luminous Flux:

600lm

Nominal Life:

10,000 hours

Dimmable:

Not suitable for dimming

Cap Type:

G23 2-Pin

Energy Saving:

No

Energy Efficiency Class:

New 2021 Energy Rating: G

Pre-2021: A

Rated Wattage (0.1W Precision):

9.0W

Power Factor λ:

>0.97

Weighted Energy Consumption:

12W

Rated Total Luminous Flux:

600lm

Colour Temperature:

4000K

Colour Name:

Cool White

Weighted Energy Consumption:

COL840

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

≥80%

Efficiency:

67lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Diameter:

32mm

Height:

164mm

Product Weight:

0.027kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986520714

Single Carton Length:

3.6cm

Single Carton Width:

2.2cm

Single Carton Height:

17.5cm

Single Carton Volume:

138.6cm³

Single Carton Weight:

0.039KG

Inner Carton GS1-128 Barcode:

02050189865207143750

Inner Carton Quantity:

50

Inner Carton Length:

19cm

Inner Carton Width:

23.5cm

Inner Carton Height:

18.5cm

Inner Carton Volume:

8260.25cm³

Inner Carton Weight:

2.477kg

Outer Carton GS1-128 Barcode:

020501898652071437200

Outer Carton Quantity:

200

Outer Carton Length:

40cm

Outer Carton Width:

49cm

Outer Carton Height:

20.5cm

Outer Carton Volume:

40180cm³
