Discontinued - CFL Single Turn S Type • 5W • 4000K • G23 2-Pin

New 2021 Energy Rating: G

Energy Labelling Guide


Discontinued Product - No suitable replacement available


Compact fluorescent single turn S-Type lamp (PL) 2 Pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Separate ballast/control gear required.

Stock Code: CLS5SCW

Related Products

Compact fluorescent single turn S-Type lamp (PL) 2 Pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • G23 2-Pin cap
  • 4000K cool white colour temperature
  • Colour rendering index ≥85
  • Not suitable for dimming
  • Recommended for indoor use only
  • 2 year warranty

Part Code:

CLS5SCW

Product Name:

CFL Single Turn S Type 5W 4000K G23 2 Pin

Notes:

Separate ballast/control gear required.

Nominal Wattage:

5W

Nominal Luminous Flux:

265lm

Nominal Life:

10,000 hours

Dimmable:

Not suitable for dimming

Cap Type:

G23 2-Pin

Energy Saving:

No

Energy Efficiency Class:

New 2021 Energy Rating: G

Pre-2021: B

Rated Wattage (0.1W Precision):

5.0W

Power Factor λ:

>0.96

Weighted Energy Consumption:

7W

Rated Total Luminous Flux:

265lm

Colour Temperature:

4000K

Colour Name:

Cool White

Weighted Energy Consumption:

COL840

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

≥80%

Efficiency:

53lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Diameter:

32mm

Height:

105mm

Product Weight:

0.021kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986671058

Single Carton Length:

3.6cm

Single Carton Width:

2.2cm

Single Carton Height:

11.5cm

Single Carton Volume:

91.08cm³

Single Carton Weight:

0.027KG

Inner Carton GS1-128 Barcode:

02050189866710583750

Inner Carton Quantity:

50

Inner Carton Length:

19cm

Inner Carton Width:

23.5cm

Inner Carton Height:

12.5cm

Inner Carton Volume:

5581.25cm³

Inner Carton Weight:

1.462kg

Outer Carton GS1-128 Barcode:

020501898667105837200

Outer Carton Quantity:

200

Outer Carton Length:

25.5cm

Outer Carton Width:

40cm

Outer Carton Height:

27.5cm

Outer Carton Volume:

28050cm³
