PL-CFL-DIM-5W-4000K-2G7_4Pin-CLSE5SCW
PL-CFL-DIM-5W-4000K-2G7_4Pin-CLSE5SCW
PL-CFL-DIM-5W-4000K-2G7_4Pin-CLSE5SCW

Discontinued - CFL Single Turn SE Type • Dimmable • 5W • 4000K • 2G7 4-Pin

New 2021 Energy Rating Label: Stock Code CLSE5SCW
New 2021 Energy Rating: G

Energy Labelling Guide

Discontinued Product - No suitable replacement available

Dimmable compact fluorescent single turn S-Type lamp (PL) 4 pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

Stock Code: CLSE5SCW

Related Products

PL-CFL-DIM-7W-4000K-2G7_4Pin-CLSE7SCW
CFL Single Turn SE Type • Dimmable • 7W • 4000K • 2G7 4-Pin

Stock Code: CLSE7SCW

PL-CFL-DIM-9W-4000K-2G7_4Pin-CLSE9SCW
Discontinued - CFL Single Turn SE Type • Dimmable • 9W • 4000K • 2G7 4-Pin

Stock Code: CLSE9SCW

PL-CFL-DIM-11W-4000K-2G7_4Pin-CLSE11SCW
CFL Single Turn SE Type • Dimmable • 11W • 4000K • 2G7 4-Pin

Stock Code: CLSE11SCW

Dimmable compact fluorescent single turn S-Type lamp (PL) 4 pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • 2G7 4-Pin cap
  • 4000K cool white colour temperature
  • Colour rendering index ≥85
  • Suitable for dimming
  • Recommended for indoor use only
  • 2 year warranty

Part Code:

CLSE5SCW

Product Name:

CFL Single Turn SE Type 5W Dimmable 4000K 2G7 4 Pin

Notes:

Suitable for use in emergency luminaires. Separate ballast/control gear required.

Nominal Wattage:

5W

Nominal Luminous Flux:

240lm

Nominal Life:

10,000 hours

Dimmable:

Dimmable

Cap Type:

2G7 4-Pin

Energy Saving:

No

Energy Efficiency Class:

New 2021 Energy Rating: G

Pre-2021: A

Rated Wattage (0.1W Precision):

5.0W

Power Factor λ:

>0.98

Weighted Energy Consumption:

6W

Rated Total Luminous Flux:

240lm

Colour Temperature:

4000K

Colour Name:

Cool White

Weighted Energy Consumption:

COL840

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

≥80%

Efficiency:

48lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Diameter:

37mm

Height:

88mm

Product Weight:

0.021kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986512832

Single Carton Weight:

0.027KG

Inner Carton GS1-128 Barcode:

02050189865128323750

Inner Carton Quantity:

50

Inner Carton Weight:

1.47kg

Outer Carton GS1-128 Barcode:

020501898651283237200

Outer Carton Quantity:

200

Name:
File Type:
Date Modified:
  Specification_Sheet

Jul 24 2018
