Discontinued - LED MR16 Glass COB 12V • 5W • 2700K • GU5.3

New 2021 Energy Rating: G

Energy Labelling Guide


Discontinued Product - See below for replacement product


12V energy efficient LED glass MR16 retrofit lamp.

Constructed from a full glass body to mimic the shape and size of a halogen MR16 lamp.

Features the latest low energy LED COB technology

Important Information: Crompton 12V LED Glass MR16 lamps will operate with most AC or DC 12V transformers. However, some 12V transformers may have a minimum required load which may not be met when installing low powered LEDs; these transformers may cause flickering or the LEDs not to function correctly. If in doubt, Crompton Lamps can supply a suitable LED driver (Part number: LEDDRIVER10W) which is guaranteed to drive 1x 5W LED Glass MR16. Contact Crompton Lamps for more information or for prices of our LED Driver.

Stock Code: 3293

Related Products

Replacement Products

12V energy efficient LED glass MR16 retrofit lamp.

Constructed from a full glass body to mimic the shape and size of a halogen MR16 lamp.

Features the latest low energy LED COB technology

  • 20,000 hour life
  • 10,000 switching cycles
  • GU5.3 cap
  • 40° beam angle
  • 2700K warm white colour temperature
  • Colour rendering index ≥80
  • Not suitable for dimming
  • Recommended for indoor use only
  • Instant full light
  • 3 year warranty
Important Information: Crompton 12V LED Glass MR16 lamps will operate with most AC or DC 12V transformers. However, some 12V transformers may have a minimum required load which may not be met when installing low powered LEDs; these transformers may cause flickering or the LEDs not to function correctly. If in doubt, Crompton Lamps can supply a suitable LED driver (Part number: LEDDRIVER10W) which is guaranteed to drive 1x 5W LED Glass MR16. Contact Crompton Lamps for more information or for prices of our LED Driver.

Equivalent to

35W

Halogen MR16


Running Cost
£1.84

Equivalent Running Cost
£12.85

Cost Saving
£11.01

Energy Saving
86%

Based on annual usage 7hrs/day @ £0.1437kWhr

Part Code:

3293

Product Name:

LED MR16 Glass COB 5W 12V 2700K GU5.3

LED Chip Type:

COB

Notes:

Suitable for fire rated downlights. The lamp will operate on most AC or DC 12V transformers. However, some 12V transformers may have a minimum required load which may not be met when installing low powered LEDs; these transformers may cause flickering or the LEDs not to function correctly.

Nominal Voltage:

12V

Nominal Wattage:

5W

Nominal Luminous Flux:

350lm

Nominal Beam Angle:

40°

Nominal Life:

20,000 hours

Dimmable:

Not suitable for dimming

Cap Type:

GU5.3

Energy Saving:

Yes

Equivalent Wattage:

35W Halogen MR16

Energy Efficiency Class:

New 2021 Energy Rating: G

Pre-2021: A+

Rated Wattage (0.1W Precision):

5.0W

Voltage:

12V

Operating Frequency:

50/60Hz

Power Factor λ:

>0.5V

Operating Current:

60mA

Weighted Energy Consumption:

6W

Rated Beam Angle:

40°

Rated Useful Luminous Flux:

350lm

Rated Total Luminous Flux:

380lm

Colour Temperature:

2700K

Colour Name:

Warm White

Colour Rendering Index:

≥80

Colour Consistency SDCM:

≤4

ΔUV:

±0.003

Starting Time:

Instant full light

Warm Up Time (to 60% Light Output):

<0.5 seconds

Efficiency:

70lm/W

Rated Life:

20,000 hours

Switching Cycles:

10,000

Warranty:

3 years

Diameter:

50mm

Height:

46mm

Product Weight:

0.041kg

Housing Material:

Glass

Mercury (Hg) Content:

0.0mg

Ambient Operating Temperature:

-20°C to 30°C

EAN13 Barcode:

5055579303293

Single Carton Length:

5.2cm

Single Carton Width:

5.2cm

Single Carton Height:

5.5cm

Single Carton Volume:

148.72cm³

Single Carton Weight:

0.053KG

Inner Carton GS1-128 Barcode:

02050555793032933720

Inner Carton Quantity:

20

Inner Carton Length:

11.4cm

Inner Carton Width:

28cm

Inner Carton Height:

14cm

Inner Carton Volume:

4468.8cm³

Inner Carton Weight:

0.58kg

Outer Carton GS1-128 Barcode:

020505557930329337100

Outer Carton Quantity:

100

Outer Carton Length:

29cm

Outer Carton Width:

59cm

Outer Carton Height:

15.5cm

Outer Carton Volume:

26520.5cm³

Name:
