Discontinued Product - No suitable replacement available

240V AC mains operated LED PLL.

Ideal for multiple commercial applications.

Wire to AC mains, not compatible with any ballast.

Featuring a full glass body with same dimensions as CFL PLL.

No mercury or hazardous materials.

Instant start with no warm-up time.

Important Information: Crompton Lamps LED PLL Direct to Mains 240V AC does not require a ballast and the luminaire to which it is installed may need re-wiring. If re-wiring, the ballast must be bypassed by a qualified person. Please refer to downloads section below for installation instructions before purchasing.
", "brand": { "@type": "Brand", "name": "Crompton Lamps" } } 12059 - LED PLL 25W 4000K 2G11 AC Mains Only - Crompton Lamps Ltd
12059 - LED PLL 25W 4000K 2G11 AC Mains Only
12059 - LED PLL 25W 4000K 2G11 AC Mains Only
12059 - LED PLL 25W 4000K 2G11 AC Mains Only
12059 - LED PLL 25W 4000K 2G11 AC Mains Only
12059 - LED PLL 25W 4000K 2G11 AC Mains Only
12059 - LED PLL 25W 4000K 2G11 AC Mains Only
Crompton Lamps

Discontinued - LED PLL Direct to Mains 240V AC • 25W • 4000K • 2G11

New 2021 Energy Rating Label: Stock Code 12059
New 2021 Energy Rating: F

Energy Labelling Guide

Discontinued Product - No suitable replacement available

240V AC mains operated LED PLL.

Ideal for multiple commercial applications.

Wire to AC mains, not compatible with any ballast.

Featuring a full glass body with same dimensions as CFL PLL.

No mercury or hazardous materials.

Instant start with no warm-up time.

Important Information: Crompton Lamps LED PLL Direct to Mains 240V AC does not require a ballast and the luminaire to which it is installed may need re-wiring. If re-wiring, the ballast must be bypassed by a qualified person. Please refer to downloads section below for installation instructions before purchasing.

Stock Code: 12059

240V AC mains operated LED PLL.

Ideal for multiple commercial applications.

Wire to AC mains, not compatible with any ballast.

Featuring a full glass body with same dimensions as CFL PLL.

No mercury or hazardous materials.

Instant start with no warm-up time.

  • 40,000 hour life
  • 15,000 switching cycles
  • 2G11 cap
  • 4000K cool white colour temperature
  • Colour rendering index ≥80
  • Not suitable for dimming
  • Recommended for indoor use only
  • Instant full light
  • 5 year warranty
Important Information: Crompton Lamps LED PLL Direct to Mains 240V AC does not require a ballast and the luminaire to which it is installed may need re-wiring. If re-wiring, the ballast must be bypassed by a qualified person. Please refer to downloads section below for installation instructions before purchasing.

Equivalent to

55W

CFL PLL

Running Cost
£9.18

Equivalent Running Cost
£20.19

Cost Saving
£11.01

Energy Saving
55%

Based on annual usage 7hrs/day @ £0.1437kWhr

Part Code:

12059

Product Name:

LED PLL 25W 4000K 2G11 AC Mains Only

LED Chip Type:

SMD

Notes:

Important Information: Crompton Lamps LED PLL Direct to Mains 240V AC does not require a ballast and the luminaire to which it is installed may need re-wiring. If re-wiring, the ballast must be bypassed by a qualified person. Please refer to downloads section below for installation instructions before purchasing.

Nominal Voltage:

240V

Nominal Wattage:

25W

Nominal Luminous Flux:

2700lm

Nominal Beam Angle:

280°

Nominal Life:

40,000 hours

Dimmable:

Not suitable for dimming

Cap Type:

2G11

Energy Saving:

Yes

Equivalent Wattage:

55W CFL PLL

Energy Efficiency Class:

New 2021 Energy Rating: F

Pre-2021: A+

Rated Wattage (0.1W Precision):

25.0W

Voltage:

240V

Power Factor λ:

>0.9

Operating Current:

112mA

Inrush Current:

9.6mA

Weighted Energy Consumption:

25W

Rated Beam Angle:

280°

Rated Useful Luminous Flux:

2700lm

Rated Total Luminous Flux:

2700lm

Colour Temperature:

4000K

Colour Name:

Cool White

Weighted Energy Consumption:

COL840

Colour Rendering Index:

≥80

Colour Consistency SDCM:

≤4

ΔUV:

±0.004

Starting Time:

Instant full light

Warm Up Time (to 60% Light Output):

<0.5 seconds

Lumen Maintenance Factor:

≥90%

Efficiency:

108lm/W

Rated Life:

40,000 hours

Switching Cycles:

15,000

Rated Lamp Survival Factor:

1000 hrs 5%

Warranty:

5 years

Width:

43mm

Height:

24mm

Length:

536mm

Length with Pins:

541mm

Product Weight:

0.205kg

Housing Material:

Glass

Mercury (Hg) Content:

0.0mg

Ambient Operating Temperature:

-20°C to 45°C

EAN13 Barcode:

5055579312059

Single Carton Length:

2.7cm

Single Carton Width:

4.7cm

Single Carton Height:

54.5cm

Single Carton Volume:

691.605cm³

Single Carton Weight:

0.246KG

Outer Carton GS1-128 Barcode:

02050555793120593725

Outer Carton Quantity:

25

Outer Carton Length:

27cm

Outer Carton Width:

52.5cm

Outer Carton Height:

22cm

Outer Carton Volume:

31185cm³

Name:
File Type:
Date Modified:
  A4_Flyer

Jun 12 2019
  A4_Flyer_Editable

Jun 12 2019
  Installation_Instructions

Oct 04 2018
  Specification Sheet

Feb 15 2019
  Warning_label

Oct 04 2018
