Discontinued - Melana Bulkhead Emergency Black • 15W • 4000K


Discontinued Product - See below for replacement product


Energy efficient IP66 rated integrated LED round bulkhead suitable for surface mounting.

Features an integrated 3-hour emergency module with internal indicator light. Constructed from black tough polycarbonate with an opal diffuser.

Constructed from tough corrosion resistant plastic with a black finish with opal diffuser.

Ideal for wet weather outdoor applications with IP66 rating and a IK10 impact rating.

Easy to install with loop-in / loop-out connection terminal.

Built-in safety isolating control gear with short circuit protection.

Important Information: Charging time 24hrs - Running time 3 hrs at 20% light output.

Stock Code: 10291

Energy efficient IP66 rated integrated LED round bulkhead suitable for surface mounting.

Features an integrated 3-hour emergency module with internal indicator light. Constructed from black tough polycarbonate with an opal diffuser.

Constructed from tough corrosion resistant plastic with a black finish with opal diffuser.

Ideal for wet weather outdoor applications with IP66 rating and a IK10 impact rating.

Easy to install with loop-in / loop-out connection terminal.

Built-in safety isolating control gear with short circuit protection.

  • 35,000 hour life
  • 50,000 switching cycles
  • 110° beam angle
  • 4000K cool white colour temperature
  • Colour rendering index ≥80
  • Not suitable for dimming
  • IP66 rated for wet weather outdoor use
  • Instant full light
  • 5 year warranty
Important Information: Charging time 24hrs - Running time 3 hrs at 20% light output.

Part Code:

10291

Product Name:

Melana LED Round Bulkhead 15W IP66 IK10 Emergency 4000K Black

Notes:

IP66 rated for use outdoor. Integrated 3hr emergency battery.

Nominal Voltage:

240V

Nominal Wattage:

15W

Nominal Luminous Flux:

1100lm

Nominal Beam Angle:

110°

Nominal Life:

35,000 hours

Dimmable:

Not suitable for dimming

Energy Saving:

Yes

Energy Efficiency Class:

This luminaire contains built-in LED lamps (A++, A+ or A). The lamps cannot be changed in this luminaire.

Rated Wattage (0.1W Precision):

15.0W

Voltage:

240V

Operating Frequency:

50/62Hz

Power Factor λ:

>0.9

Weighted Energy Consumption:

15W

Rated Beam Angle:

110°

Rated Useful Luminous Flux:

1100lm

Rated Total Luminous Flux:

1300lm

Colour Temperature:

4000K

Colour Name:

Cool White

Colour Rendering Index:

≥80

Colour Consistency SDCM:

≤6

ΔUV:

±0.003

Starting Time:

Instant full light

Warm Up Time (to 60% Light Output):

<0.5 seconds

Efficiency:

73lm/W

Rated Life:

35,000 hours

Switching Cycles:

50,000

Warranty:

5 years

Diameter:

308mm

Height:

89mm

Product Weight:

1.15kg

Housing Material:

Polycarbonate

Ingress Protection Code:

IP66

Impact Protection Rating:

IK10

Appliance Class:

II

Mercury (Hg) Content:

0.0mg

Ambient Operating Temperature:

-30°C to 50°C

EAN13 Barcode:

5055579310291

Single Carton Weight:

1.49KG

Inner Carton Length:

9.2cm

Inner Carton Width:

31.1cm

Inner Carton Height:

31.1cm

Inner Carton Volume:

8898.332cm³

Inner Carton Weight:

6.9kg

Outer Carton GS1-128 Barcode:

0205055579310291376

Outer Carton Quantity:

6

Outer Carton Length:

33cm

Outer Carton Width:

57cm

Outer Carton Height:

33cm

Outer Carton Volume:

62073cm³

Name:
File Type:
Date Modified:

Jun 13 2019

Jun 13 2019

Jan 02 2019

Mar 14 2019
