Discontinued - Melana Bulkhead White • 15W • 4000K

Discontinued Product - See below for replacement product

Energy efficient IP66 rated integrated LED round bulkhead suitable for surface mounting.

Constructed from white tough polycarbonate with an opal diffuser.

Constructed from tough corrosion resistant plastic with a white finish with opal diffuser.

Ideal for wet weather outdoor applications with IP66 rating and a IK10 impact rating.

Easy to install with loop-in / loop-out connection terminal.

Built-in safety isolating control gear with short circuit protection.

Dimensions: Diameter Ø 308mm - Height 89mm.

Stock Code: 6492

Energy efficient IP66 rated integrated LED round bulkhead suitable for surface mounting.

Constructed from white tough polycarbonate with an opal diffuser.

Constructed from tough corrosion resistant plastic with a white finish with opal diffuser.

Ideal for wet weather outdoor applications with IP66 rating and a IK10 impact rating.

Easy to install with loop-in / loop-out connection terminal.

Built-in safety isolating control gear with short circuit protection.

  • 35,000 hour life
  • 50,000 switching cycles
  • 110° beam angle
  • 4000K cool white colour temperature
  • Colour rendering index ≥80
  • Not suitable for dimming
  • IP66 rated for wet weather outdoor use
  • Instant full light
  • 5 year warranty
Dimensions: Diameter Ø 308mm - Height 89mm.

Part Code:

6492

Product Name:

Melana LED Round Bulkhead 15W IP66 IK10 4000K White

Notes:

IP66 rated for use outdoor.

Nominal Voltage:

240V

Nominal Wattage:

15W

Nominal Luminous Flux:

1100lm

Nominal Beam Angle:

110°

Nominal Life:

35,000 hours

Dimmable:

Not suitable for dimming

Energy Saving:

Yes

Energy Efficiency Class:

This luminaire contains built-in LED lamps (A++, A+ or A). The lamps cannot be changed in this luminaire.

Rated Wattage (0.1W Precision):

15.0W

Voltage:

240V

Operating Frequency:

50/60Hz

Power Factor λ:

>0.9

Weighted Energy Consumption:

15W

Rated Beam Angle:

110°

Rated Useful Luminous Flux:

1100lm

Rated Total Luminous Flux:

1300lm

Colour Temperature:

4000K

Colour Name:

Cool White

Colour Rendering Index:

≥80

Colour Consistency SDCM:

≤6

ΔUV:

±0.003

Starting Time:

Instant full light

Warm Up Time (to 60% Light Output):

<0.5 seconds

Efficiency:

73lm/W

Rated Life:

35,000 hours

Switching Cycles:

50,000

Warranty:

5 years

Diameter:

308mm

Height:

89mm

Product Weight:

0.85kg

Housing Material:

Polycarbonate

Ingress Protection Code:

IP66

Impact Protection Rating:

IK10

Appliance Class:

II

Mercury (Hg) Content:

0.0mg

Ambient Operating Temperature:

-30°C to 50°C

EAN13 Barcode:

5055579306492

Single Carton Weight:

1.19KG

Inner Carton Length:

9.2cm

Inner Carton Width:

31.1cm

Inner Carton Height:

31.1cm

Inner Carton Volume:

8898.332cm³

Inner Carton Weight:

5.1kg

Outer Carton GS1-128 Barcode:

0205055579306492376

Outer Carton Quantity:

6

Outer Carton Length:

33cm

Outer Carton Width:

57cm

Outer Carton Height:

33cm

Outer Carton Volume:

62073cm³

Name:
File Type:
Date Modified:
  A4_Flyer

Jun 13 2019
  A4_Flyer_Editable

Jun 13 2019
  Installation_Instructions

Jan 02 2019
  MELANA Rnd-6492-6508-15W-4000K

May 24 2019
  Specification Sheet

Mar 14 2019
  STD A4 Flyer

Jun 13 2019
  STD A4 Flyer Editable

Jun 13 2019
