CFL Double Turn DE Type • Dimmable • 10W • 3500K • G24q-1 4-Pin

Dimmable compact fluorescent double turn DE-Type lamp (PLC-E).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads, pendants and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

Related Products

Dimmable compact fluorescent double turn DE-Type lamp (PLC-E).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads, pendants and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • G24q-1 4-Pin cap
  • 3500K white colour temperature
  • Colour rendering index ≥85
  • Suitable for dimming
  • Recommended for indoor use only
  • Internally fused for safety
  • 2 year warranty

Part Code:

CLDE10SW

Product Name:

CFL Double Turn DE Type 10W Dimmable 3500K G24q-1 4 Pin

Notes:

Suitable for use in emergency luminaires. Separate ballast/control gear required.

Nominal Wattage:

10W

Nominal Luminous Flux:

600lm

Nominal Life:

10,000 hours

Dimmable:

Dimmable

Cap Type:

G24q-1 4-Pin

Energy Saving:

Yes

Energy Efficiency Class:

A

Rated Wattage (0.1W Precision):

10.0W

Voltage:

240V

Operating Frequency:

50/60Hz

Power Factor λ:

>0.965V

Weighted Energy Consumption:

11W

Running Cost
£3.67

Rated Total Luminous Flux:

600lm

Colour Temperature:

3500K

Colour Name:

White

Weighted Energy Consumption:

COL835

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

0.8

Efficiency:

60lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Width:

41mm

Height:

109mm

Product Weight:

0.056kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986537323

Single Carton Weight:

0.011KG

Inner Carton GS1-128 Barcode:

02050189865373233750

Inner Carton Quantity:

50

Inner Carton Length:

18cm

Inner Carton Width:

7.5cm

Inner Carton Height:

12cm

Inner Carton Volume:

1620cm³

Inner Carton Weight:

0.058kg

Outer Carton GS1-128 Barcode:

020501898653732337200

Outer Carton Quantity:

200
