CFL Single Turn S Type • 7W • 3500K • G23 2-Pin

Compact fluorescent single turn S-Type lamp (PL) 2 Pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Separate ballast/control gear required.

Stock Code: CLS7SW

Related Products

Compact fluorescent single turn S-Type lamp (PL) 2 Pin.

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • G23 2-Pin cap
  • 3500K white colour temperature
  • Colour rendering index ≥85
  • Not suitable for dimming
  • Recommended for indoor use only
  • 2 year warranty

Part Code:

CLS7SW

Product Name:

CFL Single Turn S Type 7W 3500K G23 2 Pin

Notes:

Separate ballast/control gear required.

Nominal Wattage:

7W

Nominal Luminous Flux:

400lm

Nominal Life:

10,000 hours

Dimmable:

Not suitable for dimming

Cap Type:

G23 2-Pin

Energy Saving:

No

Energy Efficiency Class:

B

Rated Wattage (0.1W Precision):

7.0W

Voltage:

240V

Operating Frequency:

50/60Hz

Power Factor λ:

>0.96V

Weighted Energy Consumption:

10W

Rated Total Luminous Flux:

400lm

Colour Temperature:

3500K

Colour Name:

White

Weighted Energy Consumption:

COL835

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

0.8

Efficiency:

57lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Width:

32mm

Height:

135mm

Product Weight:

0.023kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986523296

Single Carton Length:

3.6cm

Single Carton Width:

2.2cm

Single Carton Height:

14.5cm

Single Carton Volume:

114.84cm³

Single Carton Weight:

0.033KG

Inner Carton GS1-128 Barcode:

02050189865232963750

Inner Carton Quantity:

50

Inner Carton Length:

19cm

Inner Carton Width:

23.5cm

Inner Carton Height:

15.5cm

Inner Carton Volume:

6920.75cm³

Inner Carton Weight:

2.092kg

Outer Carton GS1-128 Barcode:

020501898652329637200

Outer Carton Quantity:

200

Outer Carton Length:

25.5cm

Outer Carton Width:

40cm

Outer Carton Height:

33.5cm

Outer Carton Volume:

34170cm³
