LED PLC Direct to Mains • 10W • 4000K • G24 Universal

New 2021 Energy Rating: G

Energy Labelling Guide

LED PLC direct to mains lamp, no ballast required

Ideal for multiple commercial applications.

Polycarbonate body with pull and twist adjustment ± 45° for directing light to best position.

No mercury or hazardous materials.

Instant start with no warm-up time.

Important Information: Crompton Lamps LED PLC direct to mains lamps should be wired directly to mains. DO NOT use a ballast, Warranty excludes damage that may be caused from wiring into a ballast. the luminaire to which it is installed may need re-wiring. Ballast must be bypassed by a qualified person.

Stock Code: 14923

Related Products

LED PLC direct to mains lamp, no ballast required

Ideal for multiple commercial applications.

Polycarbonate body with pull and twist adjustment ± 45° for directing light to best position.

No mercury or hazardous materials.

Instant start with no warm-up time.

  • 30,000 hour life
  • 15,000 switching cycles
  • G24 universal cap. Suitable for G24 2-Pin and G24 4-Pin fittings
  • 110° beam angle
  • 4000K cool white colour temperature
  • Colour rendering index ≥80
  • Not suitable for dimming
  • Recommended for indoor use only
  • Instant full light
  • 4 year warranty
Important Information: Crompton Lamps LED PLC direct to mains lamps should be wired directly to mains. DO NOT use a ballast, Warranty excludes damage that may be caused from wiring into a ballast. the luminaire to which it is installed may need re-wiring. Ballast must be bypassed by a qualified person.

Equivalent to

26W

CFL PLC


Running Cost
£3.67

Equivalent Running Cost
£9.55

Cost Saving
£5.88

Energy Saving
62%

Based on annual usage 7hrs/day @ £0.1437kWhr

Part Code:

14923

Product Name:

LED PLC AC Direct to Mains 10W 4000K

LED Chip Type:

SMD

Notes:

Important Information: Crompton Lamps LED PLC lamp should be wired direct to mains. DO NOT use a ballast, Warranty excludes damage that may be caused from wiring into a ballast.

Nominal Voltage:

240V

Nominal Wattage:

10W

Nominal Luminous Flux:

1100lm

Nominal Beam Angle:

110°

Nominal Life:

30,000 hours

Dimmable:

Not suitable for dimming

Cap Type:

G24d-3 2 Pin

Energy Saving:

Yes

Equivalent Wattage:

26W CFL PLC

Energy Efficiency Class:

New 2021 Energy Rating: G

Rated Wattage (0.1W Precision):

10.0W

Voltage:

240V

Operating Frequency:

50/60Hz

Power Factor λ:

>0.9

Operating Current:

44mA

Weighted Energy Consumption:

10W

Rated Beam Angle:

110°

Rated Total Luminous Flux:

1100lm

Colour Temperature:

4000K

Colour Name:

Cool White

Weighted Energy Consumption:

COL840

Colour Rendering Index:

≥80

Colour Consistency SDCM:

≤6

ΔUV:

±0.005

Starting Time:

Instant full light

Warm Up Time (to 60% Light Output):

<0.5 seconds

Efficiency:

110lm/W

Rated Life:

30,000 hours

Switching Cycles:

15,000

Warranty:

4 years

Diameter:

34mm

Height:

171mm

Housing Material:

Polycarbonate

Mercury (Hg) Content:

0.0mg

Ambient Operating Temperature:

-20°C to 30°C

EAN13 Barcode:

5055579314923

Inner Carton GS1-128 Barcode:

02050555793149233710

Inner Carton Quantity:

10

Outer Carton GS1-128 Barcode:

020505557931492337100

Outer Carton Quantity:

100
